5PinThreadedM12CordsetswithShield—SingleEnded
Model Length Style Dimensions Pinout(Female)
MQDEC2-506RA 2m(6.56ft)
RightAngle
32 Typ.
[1.26"]
30 Typ.
[1.18"]
ø 14.5 [0.57"]
M12 x 1

MQDEC2-515RA 5m(16.4ft)
MQDEC2-530RA 9m(29.5ft)
MQDEC2-550RA 15m(49.2ft)
MQDEC2-575RA 23m(75.44ft)
MQDEC2-5100RA 31m(101.68ft)
Button Map from RSD1 to Sensor
ThesensormaybeoptionallyconnectedtotheBannerRSD1remotedisplayaccessory.RefertothistablefortheRSD1but
tonassociationwithyoursensor.
Button association between the RSD1 and the Q4X/Q5X sensors
Device UpButton DownButton EnterButton EscapeButton
RSD1
   
Q4XandQ5X
  
N/A
