Banner Q5X - Chapter 5 Specifications; Power, Beam, Environmental, and IO-Link Specs; Performance, Response Speed, and Repeatability

July 25, 2023
Q5X With Dual Discrete Outputs And IO-Link Instruction Manual


39
Chapter Contents
FCC Part 15 Class A ......................................................................................................................................................................................... 42
Industry Canada ICES-003(A)........................................................................................................................................................................... 42
Dimensions........................................................................................................................................................................................................ 42
Q5X Dual Discrete with IO-Link Performance Curves ...................................................................................................................................... 43

Power and Beam Specifications
Supply Voltage (Vcc)
10 to 30 V DC (Class 2 supply) (10% max ripple within limits)
Supply Protection Circuitry
Protected against reverse polarity and transient overvoltages
Power and Current Consumption, exclusive of load
2000 mm and 3000 mm models: < 1 W
5000 mm model: < 1.4 W
10000 mm model: < 1.4 W
Sensing Beam
Visible red Class 2 laser models, 650 nm
Sensing Range
2000mmmodel:95mmto2000mm(3.74into78.74in)
3000 mm model: 95 mm to 3000 mm (3.74 in to 118.11 in)
5000 mm model: 50 mm to 5000 mm (2 in to 16.4 ft)
10000 mm model: 50 to 10000 mm (2 in to 32.8 ft)
Delay at Power Up
< 2.5 s
Boresighting
2000mmmodel:±43mmat2000mm
3000mmmodel:±65mmat3000mm
5000 mm model: ±86 mm at 5000 mm
10000 mm model: ±172 mm at 10000 mm
Housing and Construction
Construction
Housing: ABS
Lens cover: PMMA acrylic
Lightpipe: polycarbonate
Connector
Integral 4-pin M12 male quick-disconnect connector
Maximum Torque
Sidemounting:1N·m(9in·lbs)
IO-Link Interface
IOLinkRevisionV1.1
Smart Sensor Profile: Yes
Baud Rate: 38400 bps
Process Data In Length: 32 bits
Process Data Out Length: 8 bits
Minimum Cycle Time: 3.6 ms
IODD files: Provides all programming options of the display,
plus additional functionality.
EnvironmentalRating
IP67perIEC60529
Vibration
MIL-STD-202G, Method 201A (Vibration: 10 Hz to 55 Hz, 0.06
inch (1.52 mm) double amplitude, 2 hours each along X, Y
and Z axes), with device operating
OperatingConditions
–10°Cto+50°C(+14°Fto+122°F)
35% to 95% relative humidity
Shock
MIL-STD-202G, Method 213B, Condition I (100G 6x along X,
Y, and Z axes, 18 shocks), with device operating
Storage Temperature
–25°Cto+70°C(–13°Fto+158°F)
Performance and Output Ratings
Output Configuration
Channel 1: IO-Link, Push/pull output, configurable PNP or
NPNoutput
Channel 2: Multi-function remote input/output, configurable
PNPorNPN,orpulsefrequencymodulatedoutput
Response Speed
2000mmmodel:Userselectable3,5,15,25,or50ms
3000mmmodel:Userselectable
5000mmmodel:Userselectable2,5,15,50,or250ms
10000 mm model: User selectable 2, 5, 15, 50, or 250 ms
Ambient Light Immunity
2000 mm model:
5000luxat1m
2000luxat2m
5000 and 10000 mm models: 5000 lux
Temperature Effect (Typical) for 2000 and 3000 mm Models
< 0.5 mm/°C at < 500 mm
<1.0mm/°Cat<1000mm
< 2.0 mm/°C at < 2000 mm
< 5 mm/°C for < 3000 mm
Specifications
Chapter 5
© Banner Engineering Corp.
