Banner Q5X - Reference Targets; RSD1 Remote Display

July 25, 2023
Q5X With Dual Discrete Outputs And IO-Link Instruction Manual


57
•
•
•
•
•
•
•
SMBQ5XM4F
Fixingplatesformountingtobackofsensor
Stainlesssteelplates
Customersuppliedmountingplatethicknessminimum2mmmaxi
mum4mmwithscrewsincludedinkit

25
8
3.4

ReferenceTargets
All measurements are listed in millimeters, unless noted otherwise.
BRTQ4X60X18
Referencetargetforclearobjectdetectionordualmodeapplications
FDAgradeacetalmaterial
18
6
60

BRTQ4X60X50
Referencetargetforclearobjectdetectionordualmodeapplications
FDAgradeacetalmaterial
50
6
60

RSD1 Remote Display
UsetheoptionalRSD1forremotemonitoringandconfiguringcompatibledevices.
RefertotheRSD1instructionmanual(p/n199621)orquickstartguide(p/n199622)formoreinformation.See"Accessories"
on page 55fortherequiredcordsets.
RSD1RemoteDisplay
Model OutputAandB Dimensions Male Wiring
RSD1QP Configurable
78.0
[3.07]
68.0
[2.68]
28.0
[1.10]

1
4
5
3
2

Brown
1.
White
2.
Blue
3.
Black
4.
Gray
5.
© Banner Engineering Corp.
