Q5X With Dual Discrete Outputs And IO-Link Instruction Manual


15
Chapter Contents
Channel1andChannel2(CH1/CH2).............................................................................................................................................................. 15
Setup Mode ....................................................................................................................................................................................................... 15
ManualAdjustments ......................................................................................................................................................................................... 26
Remote Input..................................................................................................................................................................................................... 26
Locking and Unlocking the Sensor Buttons....................................................................................................................................................... 28
Button Instructions............................................................................................................................................................................................. 28
Remote Input Instructions ................................................................................................................................................................................. 28
TEACHProcedures.......................................................................................................................................................................................... 29
PulseFrequencyModulation(PFM)Output(PULS) ......................................................................................................................................... 36
SyncMaster/Slave ........................................................................................................................................................................................... 36

Programthesensorusingthebuttonsonthesensorortheremoteinput(limitedprogrammingoptions).
In addition to programming the sensor, use the remote input to disable the buttons for security, preventing unauthorized or
accidentalprogrammingchanges.See"Locking and Unlocking the Sensor Buttons" on page 28formoreinformation.
Channel1andChannel2(CH1/CH2)
PressCH1/CH2buttontoswitchbetweenChannel1andChannel2.
Within each channel, there are options specific to that channel. For settings that are common to both channels, the menus
areonlyavailableinChannel1.ThedefaultisChannel1.
To switch between Channel 1 and Channel 2:
IfneitherSELECTnorCH1/CH2arepressedafterstep2,thenewselectionflashesslowlyforafewseconds,thenflashes
quicklyandthesensorautomaticallychangestheChannelandreturnstoRunmode.
Setup Mode
AccessSetupmodeandthesensormenufromRunmodebypressingandholdingMODEforlongerthan2seconds.
Use+and-tonavigatethroughthemenu.PressSELECTtoselectamenuoptionandaccessthesubmenus.Use+and-to
navigatethroughthesubmenus.PressSELECTtoselectasubmenuoptionandreturntothetopmenu,orpressand
holdSELECTforlongerthan2secondstoselectasubmenuoptionandreturnimmediatelytoRunmode.
ToexitSetupmodeandreturntoRunmode,navigatetoEndandpressSELECT.
NOTE: Thenumberthatfollowsamenuoption,forexampletch1, indicates the channel that is selected.
For menu items without a number (excluding submenu items), these menu options are only available from
Channel1andthesettingsapplytobothchannels.
Sensor Programming
Chapter 3
PressandholdCH1/CH2forlongerthan2seconds.Thecurrentselectiondisplays.
1.
PressCH1/CH2again.Thenewselectionflashesslowly.
2.
PressSELECTtochangetheChannelandreturntoRunmode.
3.
