Banner Q5X - Dual (Intensity + Distance) (duAL)

July 25, 2023
Q5X With Dual Discrete Outputs And IO-Link Instruction Manual


35
Expected TEACH Behavior for One-Point Background Suppression
Condition TEACHResult Display
One valid TEACH point
If an Offset is applied, the TEACH point is
stillvalid
Sets a switch point in front of the taught distance equal to
thenonuniformreflectivityminimumobjectseparation.
Theswitchpointdistanceflashesonthedis
play.
OneinvalidTEACHpoint Setsaswitchpointat120cm.
bGSandtheswitchpointdistanceflashal
ternatelyonthedisplay.
OnevalidTEACHpointthat,afteroffset,be
comesinvalid
Setsaswitchpointat120cm.
oFStandtheswitchpointdistanceflashal
ternatelyonthedisplay.
Dual (Intensity + Distance) (duAL)
Dual(intensity+distance)TEACHrecordsthedistanceandamountoflightreceivedfromthereferencesurface.
The output switches when an object passing between the sensor and the reference surface changes the perceived distance
oramountofreturnedlight.Formoreinformation,see"Additional Information" on page 49.
NOTE: Tousethefollowinginstructions,setthesensortotch=duAL. The DYN, FGS, and BGS indicators
areamber.
NOTE: To program the sensor using remote input, remote input must be enabled (out2=SEt).

1
2 3

Present the target.
Method Action Result
Push Button
Remote Input
Presentthereferencetarget. Thetarget'smatchpercentagedisplays
1.
Start the TEACH mode.
Method Action Result
Push Button PressandholdtheTEACHbuttonformorethan2seconds.
LightOperate:SEtandonflashonthedis
play.The DYN, FGS, and BGS indicators
flash.
DarkOperate:SEtandoFFflashonthe
display.TheDYN,FGS,andBGSindica
tors flash.
Remote Input Noactionisrequired. N/A
2.
Teach the sensor.
3.
