Q5X With Dual Discrete Outputs And IO-Link Instruction Manual


34
One-Point Background Suppression
Switch
Point
1
2 3
NOTE: Thesensormustbesettotch=bGStousethefollowinginstructions.TheBGSindicatorisamber
toindicateBackgroundSuppressionmode.
NOTE: To program the sensor using remote input, remote input must be enabled (out2=SEt).
See"Q5X Dual Discrete with IO-Link Performance Curves" on page 43fortheminimumobjectseparation.
Present the target.
Method Action Result
Push Button
Present the target. The sensor-to-target distance must be within the sensor's
range.
Thetarget'smeasurementvaluedisplays.
Remote Input
1.
Start the TEACH mode.
Method Action Result
Push Button PressandholdTEACHforlongerthan2seconds.
Light Operate
SEtandoFFflashalternatelyonthedis
play.The BGS indicator flashes.
Dark Operate
SEtandonflashalternatelyonthedis
play.The BGS indicator flashes.
Remote Input Noactionisrequired.  N/A
2.
Teach the sensor.
Method Action Result
Push Button PressTEACHtoteachthetarget.
The new switch point flashes rapidly and
thesensorreturnstoRunmode.
Remote Input Singlepulsetheremoteinput.

T

3.
