Dual Mode Considerations for Clear and Transparent Object
Detection
TheQ5Xisabletodetecttheverysmallchangescausedbytransparentandclearobjects.Atransparentobjectcanbede
tectedeitherbyachangeinintensity,distance,orbyadoublepeakreflection.
TheQ5Xsensorcanbetaughtnonidealreferencesurfaces,suchassurfacesoutsideofthesensorrangeorverydarksur
faces. Teaching non-ideal reference surfaces may enable applications other than transparent or clear object detection, but
bestresultsfortransparentorclearobjectdetectionrequireastablereferencesurface.
Thedisplayshowsthematchpercentagetothetaughtreferencepoint.Theuseradjustableswitchpointdefinesthesensitivi
tyandtheoutputswitcheswhenthematchpercentagetothereferencepointcrossestheswitchpoint.Yourspecificapplica
tionmayrequirefinetuningoftheswitchpoint,butthesevaluesaretherecommendedstartingvalues:
Match percentage to taught reference point
Switchpoint(%) TypicalApplications
50(default) Default,recommendedforPETbottlesandTrays
88 Recommendedforthinfilms
50 Recommendedfortintedbrown,tintedgreen,orwaterfilledcontainers
Example mounting considerations
CC
10° or more
Up to the maximum sensing distance
Reference Surface
Separate as far as possible
◦
◦
◦
Matteordiffusesurfacefinish
Fixedsurfacewithnovibration
Drysurfacewithnobuildupofoil,water,ordust
Positionthereferencesurfacebetween200mm(20cm)andthemaximumsensingrange.
2.
Positionthetargettobedetectedasclosetothesensoraspossible,andasfarawayfromthereferencesurfaceas
possible.
3.
Anglethesensingbeamrelativetothetargetandrelativetothereferencesurface10degreesormore.
4.
