Q5X Dual Discrete with IO-Link Performance Curves
Minimum object separation distance (90% to 6% reflectance) for the 2000 mm models
Switch Point
Distance
Background
X
Y
Typical performance curves for the 2000 mm models
Minimum Separation Target to Background (mm)
Dimension
Distance to Target (mm)
Dimension X
0
10
20
30
40
50
60
70
80
0
200 400 600 800 1000 1200 1400 1600 1800 2000
