Q5X With Dual Discrete Outputs And IO-Link Instruction Manual


44
Typical performance curves for the 3000 mm models
Dimension X
0
10
20
30
40
50
60
70
80
90
100
0
500 15001000 2000 2500 3000 3500
Matte targets with a non-uniform
reflectivity: 6% to 90%
Matte targets with uniform
reflectivity: 6% to 90%
Typical performance curves for the 5000 mm models
Minimum Object Separation for 250 ms Response Time
0
0
(Dimension X)
Minimum Object Separation
1000
2000
3000
4000
5000
6% black/90% white
90% white/90% white
20
40
60
80
100
Repeatability for 250 ms Response Time
Repeatability (250 ms)
0 1000 2000 3000
4000
5000
0
6% black
18% Gray
90% white
(Dimension X)
2
4
6
8
10
12
14
1σRepeatabilityinmm(inch)
Continued on page 45
