Q5X With Dual Discrete Outputs And IO-Link Instruction Manual


32
See"Q5X Dual Discrete with IO-Link Performance Curves" on page 43fortheminimumobjectseparation.
Expected TEACH Behavior for Dynamic Background Suppression
Condition TEACHResult Display
Two valid distances that are greater than or
equaltothehorizontalminimumobjectsepa
ration
Setsaswitchpointbetweenthetwotaughtdistances.
Theswitchpointdistanceflashesonthedis
play.
Two valid distances that are less than the
horizontalminimumobjectseparation
Sets a switch point in front of the furthest taught distance
equaltotheuniformreflectivityminimumobjectsepara
tion.
bGSandtheswitchpointdistanceflashal
ternatelyonthedisplay.
One valid distance with one invalid TEACH
point
Sets a switch point between the one taught distance and
themaximumrange.
obJtandtheswitchpointdistanceflashalter
natelyonthedisplay.
TwoinvalidTEACHpoints
Sets a switch point for the currently selected channel at
120cm.
bGSandtheswitchpointdistanceflashal
ternatelyonthedisplay.
One-Point Window (Foreground Suppression) (FGS)
One-point window sets a window (two switch points) centered around the taught target distance.
LossofsignalistreatedasadetectioninOnePointWindowmode.Thesizeofthetaughtwindowistheverticalminimumob
jectseparation.See"Q5X Dual Discrete with IO-Link Performance Curves" on page 43.
ManuallyadjustthewindowsizefromRunmodeusing+and-.
One-Point Window (Foreground Suppression)
Switch
Point
Switch
Point
1
2 3
In order to reliably detect changes from the taught background, if multiple laser reflections are returning to the sensor, the
outputstatusistreatedasthoughthetargetisoutsideofthetaughtwindow.Thedisplayalternatesbetween2-Lrandthe
measureddistance.Realignthelasertoavoidlightreflectingoffofmultipletargetsifthisextralevelofverificationisnotde
sired.
NOTE: Thesensormustbesettotch=FGStousethefollowinginstructions.TheFGSindicatorisamber
toindicateOnePointWindow(ForegroundSuppression)mode.
NOTE: To program the sensor using remote input, remote input must be enabled (out2=SEt).
Method Action Result
Push Button PressTEACHtostopteachingthesensor.
The new switch point flashes rapidly and
thesensorreturnstoRunmode.
Remote Input Singlepulsetheremoteinput.

T

Present the target.
1.
