Q5X With Dual Discrete Outputs And IO-Link Instruction Manual


29
TEACHProcedures
Usethefollowingprocedurestoteachthesensor.
TocancelaTEACHprocedure,pressTEACHforlongerthan2seconds,orholdtheremoteinputhighforlongerthan2sec
onds.CnCLmomentarilydisplayswhenaTEACHprocedureiscanceled.
Afteranyteachoperationstarts,thedisplaytemporarilyflashesCH1orCH2toconfirmwhichchanneliscurrentlyselected.
Two-Point Static Background Suppression (2-Pt)
TwopointTEACHsetsasingleswitchpoint.The sensor sets the switch point between two taught target distances, relative to
the shifted origin location.
Two-Point Static Background Suppression (Light Operate shown)
1
4
2 3 5
NOTE: Thesensormustbesettotch=2-Pttousethefollowinginstructions.
NOTE: To program the sensor using remote input, remote input must be enabled (out2=SEt).
Continued from page 28
Action Result
Doublepulse the remote input to lock the sensor.
T T
T
Loc displays and the sensor returns to Run
mode.
Triple-pulse the remote input to apply the operator
lock to the sensor
T T
T
T
T
0Loc displays and the sensor returns to Run
mode
Present the target.
Method Action Result
Push Button
Present the first target. The sensor-to-target distance must be within the
sensor'srange.
Thetarget'smeasurementvaluedisplays.
Remote Input
1.
Start the TEACH mode.
Method Action Result
Push Button PressandholdTEACHforlongerthan2seconds.
SEtand1Stflashalternatelyonthedis
play.The DYN, FGS, and BGS indicators
flash.
Continued on page 30
2.
