B=7×M3×0.5
Boltthread(A):3/816×2¼inforSMBQ5XFA:M101.5×50forSMBQ5XFAM10;n/a;noboltincluded.Mountsdirectlyto12mm(½in)rodsfor
SMBQ5XFAM12
SMBAMSQ5XIPRA
Enclosedbracket
13ga.Stainlesssteelwithborosilicateglasswindow
Rightanglemountplate

R3.4
2 X
68
45
104
34
Ø6.7

SMBAMSQ5XIPP
Enclosedbracket
13gastainlesssteelwithaborosilicateglasswindow
Flatmountplate
R3.4
2 X
68
143
45
34
Ø6.7

SMBQ5XDT
Clampbracketmountstosensordovetail
Translationadjustmentforsensoralignment
Aluminumclamp6.5mmmaximumplatethickness

2X
20
20
14

SMBAMSQ5XP
FlatSMBAMSseriesbracket
Articulationslotsfor30degrotation
13ga.304stainlesssteel

143
68
2X R3.4
Ø6.5

SMBAMSQ5XRA
RightangleSMBAMSseriesbracket
Articulationslotsfor30degrotation
13ga.304stainlesssteel

104
68
50
45
2X R3.4
Ø6.7

