Temperature Effect (Typical) for 5000 and 10000 mm Models
< 0.5mm/°C for up to 3000 mm
< 0.75mm/°C for up to 5000 mm
< 2.0 mm/C for up to 7500 mm
< 6.0 mm/C for up to 10000 mm
Remote Input
Allowable Input Voltage Range: 0 to Vsupply
ActiveHigh(internalweakpulldown):Highstate>(Vsupply–
2.25 V) at 2 mA maximum
Active Low (internal weak pull-up): Low state < 2.25 V at 2 mA
maximum
Application Note
For optimum performance, allow 10 minutes for the sensor to
warm up for the 2000 mm models and 20 minutes for the
5000 and 10000 mm models.
Advanced Capabilities
Output Rating
Current rating: 50 mA maximum
Blackwirespecificationsperconfiguration
IOLinkPush/Pull
OutputHigh: ≥Vsupply2.5V
OutputLow: ≤2.5V
PNP
OutputHigh: ≥Vsupply2.5V
OutputLow: ≤1V(loads≤1MegΩ)
NPN
OutputHigh: ≥Vsupply2.5V(loads≤50kΩ)
OutputLow: ≤2.5V
Whitewirespecificationsperconfiguration
PNP
OutputHigh: ≥Vsupply2.5V
OutputLow: ≤2.5V(loads≤70kΩ)
NPN
OutputHigh: ≥Vsupply2.5V(loads≤70kΩ)
OutputLow: ≤2.5V
Discrete Output Distance Repeatability
Distance(mm)
Repeatability (2000
mmModels)
Repeatability (3000 mm Models)
95to300 ±0.5mm ±0.5mm
300to1000 ±0.25% ±0.25%
1000to2000 ±0.25% ±0.25%
2000 to 3000 ±1.0%
See the charts for the Repeatability of the 5000 mm and
10000 mm models.
Typical Excess Gain for the 2000 mm Model
High Excess Gain (Standard Excess Gain) Using a 90% White Card
Response
Speed(ms)
at100mm at500mm at1000mm at2000mm
3 125 50 15 4
5 125 50 15 4
15 575(175) 250(75) 70(25) 15(6)
25 1000(650) 450(250) 125(70) 30(15)
50 2000(1000) 900(450) 250(125) 60(30)
Standardexcessgainisavailablein15,25,and50msre
sponse speeds; standard excess gain provides increased
noise immunity.
Typical Excess Gain for the 3000 mm Model
High Excess Gain (Standard Excess Gain) Using a 90% White Card
Response
Speed (ms)
at 100 mm at 500 mm at 1000 mm at 2000 mm at 3000 mm
200 0 25 6 3
200 0 25 6 3
920 400 100 25 12
1600 700 200 50 25
3200 1400 400 100 50
Standardexcessgainisavailablein15,25,and50msre
sponse speeds; standard excess gain provides increased
noise immunity.
Typical Excess Gain for the 5000 mm Model
Typical Excess Gain Using a 90% White Card (Performance Gain Mode)
at50mm at600mm at1000mm at2000mm at5000mm
50 400 400 175 30
Excess gain is consistent for 15, 50, and 250 ms response
speeds. Excess gain is approximately 10% lower in 2 ms and
5 ms response speed modes.
Excess gain in black gain mode is approximately three times
higherthaninperformancegainmode.Itisusefulforlowre
flectivity targets.
Excess gain in shiny gain mode is approximately one-third the
excess gain of performance gain mode values. It is useful for
highly reflective targets.
