Barco DP2K-E series User Manual

8. ICMP
SMPTE
Standard
Source Resolution
Frame R ate Display Rate
Scan Type
SMPTE 292M
1920x1080 23.976
24
25
29.97
30
23.976
24
25
29.97
30
Progress ive
SMPTE 292M
2048x1080 23.976
24
25
29.97
30
23.976
24
25
29.97
30
Segmented frame
The formats in single link and dual link table are supported in 4:2:2 Y CBCR 10 bits/component. The dual link (2×) formats are m ainly
used for s tereoscopic and/or HFR content.
Dual link (2xSMPTE 372M) formats
SMPTE
Standard
Source Resolution
Frame R ate Display Rate
Scan Type
SMPTE 274M 1920x1080 23.976
24
25
29.97
30
23.976
24
25
29.97
30
Progress ive
SMPTE 274M 1920x1080 50
59.94
60
25
29.97
30
Interlaced
SMPTE 274M
SMPTE RP211
1920x1080 23.976
24
25
29.97
30
23.976
24
25
29.97
30
Segmented frame
SMPTE 428-9
2048x1080 24
25
30
24
25
30
Progress ive
SMPTE 428-9
2048x1080 24
25
30
24
25
30
Segmented frame
The formats in the above table support both RGB (4:4:4) and Y CBC R (4:2:2 and 4:4:4) color encoding using 10 or 12 bits/compo nent.
RGB
• 4:4:4 10 bits/component
• 4:4:4 12 bits/component
YC
B
C
R
• 4:2:2 12 bits/component
• 4:4:4 10 bits/component
• 4:4:4 12 bits/component
56
R5906693 DP2K-E SERIES 19/06/2015
