154 Encore Presentation System • User’s Guide
5. Menu Orientation
Output Menu
táÇÉ=pÅêÉÉå=pÉííáåÖë=jÉåì
From the Output Menu, press {WIDE SCREEN} to display the Wide Screen Settings
Menu
.
Figure 5-14. Wide Screen Settings Menu (sample)
The Wide Screen Settings Menu provides tools for wide screen setup and adjustment.
Note that the
{WIDE SCREEN} softkey only appears when the destination is configured as
a wide screen. Refer to the “
Destination Setup Menu” section on page 166 for details.
The following functions are provided:
• Total Projectors — indicates the total number of Video Processors as defined in
the wide screen configuration. This field is for information only.
• Total H Res — sets the total number of horizontal pixels in the overall wide screen
display. The formula is:
# screens * horizontal output resolution -
(overlap width * (# screens - 1))
S If two screens are used, each with an output resolution of 1024 x 768 and an
overlap of 200 pixels, the
Total H Res is:
2 * 1024 - (200 * 1) = 1848
As you adjust the Total H Res, the Overlap Width value tracks and the wide
screen markers adjust accordingly.
• Total V Res — displays the vertical resolution. This field is fixed.
• Background Format — selects the method by which your background graphics
were originally produced:
~ Edge-butted — choose this option if your background graphics were
produced with no pre-data doubling (e.g., typically from a multi-head
graphics card).
~ Overlapped — choose this option if your backgrounds were produced
using pre-data doubling (e.g., from a Dataton
®
Watchout system).
Total V Res
Marker Mode
Overlap Width
Total H Res
Alignment Test Pattern
Data Doubling
1808
[ 768 ]
240
Off
On
B
A
C
K
N
A
V
A
D
J
WIDE SCREEN SETTINGS
Total Projectors [ 2 ]
Justification Center
On
Background Format Edge-Butted
To Next Page
