Encore Presentation System • User’s Guide 155
5. Menu Orientation
Output Menu
• Marker Mode — enables and disables the wide screen markers, to show the
boundaries of active data. In Chapter 7, refer to the “
Wide Screen Markers”
section on page 283 for details.
• Overlap Width — sets the overlap (in pixels) between projectors. As you adjust,
the
Total H Res value tracks and the wide screen markers adjust accordingly.
• Alignment Test Pattern — enables or disables the test pattern used for
performing projector lens shift and registration adjustments.
• Data Doubling — enables or disables data doubling. Typically, the function is
only disabled when unscaled background sources are pre-data doubled. In
Chapter 3, refer to the “
Overview of Edge-Blending Technology” section on
page 89 for more information.
• Justification — sets the desired wide screen justification, either Center or Left.
Once set, wide screen markers adjust accordingly.
In the
Feathering section:
• Mode — enables or disables edge feathering.
• Gamma — sets gamma for the feathered regions.
~ Adjustment range: 1.0 to 5.0
Note
Barco offers the Configurator application to assist with wide
screen setup.
