222 Encore Presentation System • User’s Guide
5. Menu Orientation
Background Input Setup Menu
_~ÅâÖêçìåÇ=E~åÇ=aphF=jÉåì=cìåÅíáçåë=Ô=asf=qóéÉ
The figure below illustrates a sample BG Input Setup Menu when “DVI” is selected as the
background type.
Figure 5-69. BG (and DSK) Input Setup Menu — DVI Type (sample)
The following functions are provided for a DVI background or DSK source:
• Format — this line performs two functions:
~ Displays the resolution that is automatically determined by the FORCE
ACQUIRE
function.
~ Manually sets the resolution of the incoming source. Once the format is
selected, press
{APPLY FORMAT} to “accept” and activate the format.
• For the two Crop settings:
~ If the source’s input resolution matches the output resolution, or if output
resolution is
larger than input resolution, Crop settings are bracketed.
~ If input data is smaller than output resolution, the area around the active
data is set to black, and input data is centered in the screen.
~ If the source’s input resolution is larger than the output resolution, the H
Offset
and V Offset values can be used to choose which portion of the
background you want to display.
~ Press {RESET} to reset the H and V offsets to 0.
• Press {SAVE} to save the selected background input configuration.
• Press {APPLY FORMAT} to “activate” the selected format.
• Press {FORCE ACQUIRE} to automatically detect the input signal resolution and
update the display
Format field accordingly.
Note
The functions described below also apply to the DSK Input
Setup Menu
, when “DVI” is selected as the DSK type.
ID ALL
N
A
V
A
D
J
BG INPUT SETUP BG_A
S
A
V
E
Destination [ 1 ]
Type DVI
R
E
S
E
T
FORCE
ACQUIRE
Format 1024 x 768 @ 59.94
Crop: [ 0 ]H Offset
[ 0 ]V Offset
APPLY
FORMAT
