3. Hardware Installation
Installation
4. Source Connections — connect DVI outputs from Processors one, two and
three to Processor #4’s scaler inputs:
~ Connect Processor #1 DVI Program 2 Output to Processor #4 input 1A.
~ Connect Processor #1 DVI Preview 2 Output to Processor #4 input 1B.
~ Connect Processor #2 DVI Program 2 Output to Processor #4 input 2A.
~ Connect Processor #2 DVI Preview 2 Output to Processor #4 input 2B.
~ Connect Processor #3 DVI Program 2 Output to Processor #4 input 3A.
~ Connect Processor #3 DVI Preview 2 Output to Processor #4 input 3B.
5. Output Connections —
~ Connect Processor #4’s analog or digital Preview Output to the input of
your “widescreen preview” monitor.
~ (Optional, for video recording) Connect Processor #4’s analog or digital
Program Output 1 or 2 to the input of the ImagePRO. Connect the
ImagePRO’s output to the input of your video recorder. Refer to the
“
ImagePRO User’s Guide” for connection and setup details.
6. Power Connection — connect AC power cords to the AC Power Connectors on
the rear of Processor #4, the monitor and the ImagePRO.
7. System ID — Using the Unit ID Selector, set the ID of Processor #4 to 4.
8. Power On — all power on instructions are covered in Chapter 6.
With all connections made, continue with Chapter 4, “
Controller Orientation” on page 97.
`çãéäÉíáåÖ=táÇÉ=pÅêÉÉå=mêÉîáÉï=pÉíìé
Once you are familiar with the Controller, with all system setup procedures and with basic
Encore operations, you must complete the following operational setup steps — in order to
properly configure Video Processor #4 and its Preview output.
Multi-button method — Use the following steps to complete your wide screen
preview setup, using
six individual buttons for Video Processor sources:
1. Set up Video Processor #4 as a unique Encore destination. In Chapter 6, refer to
the “
Destination Setup” section on page 257.
2. On the Controller, identify six buttons on the Source Selection Bus that you want
to use as the inputs from Processors 1, 2 and 3.
3. Set up these designated inputs as direct DVI connections. In Chapter 6, refer to
the “
Input Setup” section on page 271 for details.
Note
The Program 2 Output is used because it is a clean feed,
without any edge feathering or data doubling information
present in the signal.
Note
Each Processor must have a unique ID.
Note
Two different methods are available for connecting Video
Processor sources:
multi-button and single button.
