Specifications, Requirements, and Precautions AW00123409000
4 Basler ace USB 3.0
1.3 General Specifications
1.3.1 Cameras with CCD Sensor
Specification acA640-90um/uc acA640-120um/uc
Resolution
(H x V pixels)
um: 659 x 494
uc: 658 x 492
um: 659 x 494
uc: 658 x 492
Sensor Type Sony ICX424AL/AQ
Progressive scan CCD
Global shutter
Sony ICX618 ALA/AQA
Progressive scan CCD
Global shutter
Optical Size 1/3" 1/4"
Effective Sensor Diagonal 6.1 mm 4.7 mm
Pixel Size (H x V) 7.4 µm x 7.4 µm 5.6 µm x 5.6 µm
Max. Frame Rate
(at full resolution)
100 fps 120 fps
Mono/Color Mono or color
(color models include a Bayer pattern RGB filter on the sensor)
Data Output Type USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)
Pixel Formats Mono Models: Mono 8 Mono 12p
Mono 12
Color Models: Mono 8 RGB 8
Bayer BG 8 BGR 8
Bayer BG 12 YCbCr422_8
Bayer BG 12p
ADC Bit Depth 12 bits
Synchronization Via hardware trigger, via software trigger or free run
Exposure Time Control Via hardware trigger or programmable via the camera API
Camera Power
Requirements
Nominal +5 VDC; SELV and LPS compliant and in accord with the Universal Serial
Bus 3.0 specification; supplied via the camera’s USB 3.0 port.
≈2.7 W (typical) @ 5 VDC,
≈3.0 W (max.)
≈2.4 W (typical and max.) @ 5 VDC
I/O Lines 1 opto-isolated input line, 1 opto-isolated output line, and 2 direct-coupled GPIO
lines; power supplies must meet the SELV and LPS requirements
Lens Mount C-mount, CS-mount
Table 1: General Specifications
