Basler acA2040-55 User Manual

Features AW00123409000
218 Basler ace USB 3.0
 Camera parameters for camera control (e.g. exposure time, gain, ROI position and size,
see also Section 7.7.2.1).
 Sequencer set related parameters for sequencer control. The parameters define the
details of advancing from one sequencer set to the next. This includes the possibility of
choosing between different "paths" for advance, thus allowing to choose between different
sequencer sets (see Figure 87 and Section 7.7.2.2).
Fig. 87: Sequencer Parameters of Sequencer Set with Index Number J (Most Parameter Values as Examples)
7.7.2.1 Camera Parameters
Each sequencer set controls the parameter values for the following camera parameters.
AcquisitionFrameRate DeviceLinkThroughputLimit
AcquisitionFrameRateEnable DigitalShift
BalanceRatio ExposureTime
BinningHorizontal Gain
BinningVertical Height
BlackLevel LUTEnable
3)
CenterX OffsetX
CenterY OffsetY
ChunkEnable PixelFormat
4)
ChunkModeActive ReverseX
ColorAdjustmentHue
1) 2)
ReverseY
5)
ColorAdjustmentSaturation
1) 2)
ScalingHorizontal
ColorTransformationValue
1)
TestImageSelector
Camera parameter values
Sequencer set J
Path 0:
Sequencer Set Next:
0
Trigger Source:
Line 3
Level High
Path 1:
Sequencer Set Next:
(J+1)
Trigger Source:
Line 4
Level High
Sequencer set related parameter values
