Specifications, Requirements, and Precautions AW00123409000
20 Basler ace USB 3.0
Specification acA2440-75um acA2440-75uc
Resolution
(H x V pixels)
2464 x 2056 (full resolution)
2448 x 2048 (default resolution; see Section 1.2 on page 2)
Sensor Type Sony IMX250LLR-C
Progressive scan CMOS
Global shutter
Sony IMX250LQR-C
Progressive scan CMOS
Global shutter
Optical Size 2/3"
Effective Sensor Diagonal 11.1 mm
Pixel Size (H x V) 3.45 µm x 3.45 µm
Max. Frame Rate 75 fps (at default resolution; see Section 1.2 on page 2)
Mono/Color Mono or color
(color cameras include a Bayer pattern RGB filter on the sensor)
Data Output Type USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)
Pixel Formats Mono 8 Mono 12p
Mono 12
Mono 8 RGB 8
Bayer RG 8 BGR 8
Bayer RG 12 YCbCr422_8
Bayer RG 12p
Synchronization Via hardware trigger, via software trigger or free run
Exposure Time Control Via hardware trigger or programmable via the camera API
Camera Power
Requirements
Nominal +5 VDC; SELV and LPS compliant and in accord with the Universal Serial
Bus 3.0 specification; supplied via the camera’s USB 3.0 port.
Mono Models:
≈3.2 W (typical) @ 5 VDC
Color Models:
≈3.4 W (typical) @ 5 VDC
I/O Lines 1 opto-isolated input line, 1 opto-isolated output line, and 2 direct-coupled GPIO
lines; power supplies must meet the SELV and LPS requirements
Lens Mount C-mount
Size (L x W x H) 29.3 mm x 29 mm x 29 mm (without cylindric housing extension or connectors)
48.2 mm x 29 mm x 29 mm (with cylindric housing extension and connectors)
Weight <80 g
Conformity CE (includes RoHS), UL in preparation, FCC, GenICam V. 2.x (includes PFNC V.
2.x and SFNC V. 2.x), IP30, USB3 Vision, USB-IF in preparation, REACH
The EU Declaration of Conformity is available on the Basler website:
www.baslerweb.com
Software Basler pylon Camera Software Suite (version 4.0 or higher)
Available for Windows (x86, x64) and Linux (x86 32 bit, x86 64 bit, ARM).
Table 15: General Specifications
