Monitoring functions
Instruction handbook b maXX 5000
Document No.: 5.09021.16 Baumüller Nürnberg GmbH
230
of 328
10.2
Cyclical specified value
transmission to the fieldbus
6)
Time-out during transmission - X X X
4)
Blocking monitoring
6)7)
Drive blocked - X X - X
Signal bus
9)
Feed-in ready-to-operate X
9)
X
9)
- X
9)
-
Phase failure
7)
X X - X -
Brake resistance on
7)
X X - X -
Malfunction
7)
X X - X -
Signal bus warning
7)
X X - X -
Monitoring function Warning/error
Warning Error Adjustable threshold Adjustable reaction Reaction inhibit pulses
1)
Pulses are inhibited after a adjustable time period (not provided for BM51XX).
2)
Only if KTY/PT1000 sensors are used
3)
Threshold adjustable
4)
Reaction adjustable
5)
Not provided for BM53XX
6)
Not provided for BM50XX
7)
Not provided for BM51XX
8)
Only provided for BM51XX
9)
Not processed by BM51XX, only a message for the axis units.
X: Implemented
-: Not possible
