925.916.2 - GBINSTRUCTIONS PERTAINING TO THE INSTALLER
26. teChnICal Data
BAXI S.p.A., in its commitment to constantly improve its products, reserves the right to alter the specications contained herein at
any time and without previous warning. These Instructions are only meant to provide consumers with use information and under no
circumstance should they be construed as a contract with a third party.
Boiler model LUNA3 SYSTEM HT…MP 1.180 1.240 1.330
Category II2H3P II2H3P II2H3P
CH rated heat input kW 17,4 24,7 34
Reduced heat input kW 4,3 7 9,7
DHW rated heat output kW - - -
kcal/h - - -
CH rated heat output 75/60°C kW 16,9 24 33
kcal/h 14.534 20.640 28.380
CH rated heat output 50/30°C kW 18,3 25,9 35,7
kcal/h 15.738 22.270 30.702
Rated heat output 75/60°C kW 4,2 6,8 9,4
kcal/h 3.612 5.850 8.090
Rated heat output 50/30°C kW 4,5 7,4 10,2
kcal/h 3.870 6.360 8.770
Useful efciency according to 92/42/CEE directive —  ★★★★  ★★★★ ★★★★
Central heating system max. pressure bar 3 3 3
Expansion vessel capacity l 8 8 10
Expansion vessel pressure bar 0,5 0,5 0,5
DHW system max. pressure bar - - -
DHW system min. dynamic pressure bar - - -
DHW system min. output l/min - - -
DHW production at ∆T=25 °C l/min - - -
DHW production at ∆T=35 °C l/min - - -
Specic output (*)“D” l/min - - -
Heating circuit temperature range °C 25÷80 25÷80 25÷80
Domestic hot water temperature range °C - - -
Type — C13 - C33 - C43 - C53 - C63 - C83 - B23
Concentric ue duct diameter mm 60 60 60
Concentric air duct diameter mm 100 100 100
2-pipe ue duct diameter mm 80 80 80
2-pipe air duct diameter mm 80 80 80
Max. ue mass ow rate kg/s 0,008 0,012 0,016
Min. ue mass ow rate kg/s 0,002 0,003 0,005
Max. ue temperature °C 74 73 76
NOx class — 5 5 5
Type of gas used — G20 G20 G20
— G31 G31 G31
Natural gas feeding pressure 2H - G20 mbar 20 20 20
Propane gas feeding pressure 3P - G31 mbar 37 37 37
Power supply voltage V 230 230 230
Power supply frequency Hz 50 50 50
Rated power supply W 140 150 160
Net weight kg 44 45 46
Dimensions height mm 763 763 763
width mm 450 450 450
depth mm 354 354 354
Protection-limit against humidity and water leakages (**) IPX5D IPX5D IPX5D
(*) according to EN 625
(**) according to EN 60529
