23 Communication & Interfaces
The menu Communication & Interfaces is called up as follows:
Menu hotkey
Communication & Interfaces
The menu contains multiple sub-menus with the following
configuration options:
Menu Communication & interfaces
Network (IP) configuration
In this sub-menu, the network settings (IP settings, IP = Internet protocol) are
made for remote access from the local network.
See section Remote access from the local network.
E-mail configuration
This sub-menu configures the options for sending e-mails via PoolManager
®
.
See section E-mail functions.
Data import & export
This sub-menu provides import and export functions for various data:
 Measurement graph (export)
 Eventlog (export)
 Individual background images (import)
See section Data import & export
CAN bus interface
This sub-menu configures the CAN bus for the connection of future add-on
boxes (feature boxes). Please refer to the separate documentation for the
corresponding feature box for more information.
4-20 mA current loop outputs
This sub-menu configures the PoolManager
®
optional 4-20 mA current loop
outputs. These outputs are available as an optional add-on module (internal
plug-in module with 4 outputs 4-20 mA):
PM5-SA4 CONVERTER 4-20MA (Art. no. 127011)
The current loop outputs can be used for the following functions:
 Transmitting measured values (pH, mV, Cl / Br, temp.) as 4-20 mA current
loop signal (for data recorders, remote displays, building management
systems)
 Controlling external systems
(e.g. variable filter pumps, salt electrolysis systems)
For more details, please refer to the separate documentation for the
PM5-SA4 CONVERTER 4-20MA (Art. no. 127011).
23.1 Data import and export
The menu Data import and export provides functions for importing and
exporting various data:
 Export measurement graph
 Download measurement graphs from the PoolManager
®
(in remote access from a PC)
 Store measurement graphs to USB stick
 Automatic e-mail transmission of measurement graph (every
1...7 days to up to 3 e-mail recipients)
 In order to use the export functions for the measurement
graph, Automatic storage of measurement graphs has to be
activated in advance. This automatically saves daily
measurement graphs in PoolManager
®
for later export.
 Export eventlog
 Download eventlog from the PoolManager
®
(in remote access from a PC)
 Store eventlog to USB stick
 Load individual background images
 Load background image to the PoolManager
®
(in remote access from a PC)
 Load background image from USB stick
 USB memory stick data import & export
 Save measurement graphs to USB stick
 Save eventlog to USB stick
 Load background image from USB stick
INFO
Measurement graph export
To export measurement graphs, a start date and an
end date have to be selected first. This will then export
the measurement graphs available for the time frame
indicated.
INFO
Requirements for individual background images
 Image size 800x480 pixels
 JPEG format
 Max. 300 kB
INFO
Load individual background images from USB stick
The images on the USB stick have to be in a sub-
directory \pm5_image and meet the requirements listed
above.
INFO
Save measurement graph to USB stick
Measurement graphs are stored to a USB stick in the
directory \pm5_graph
INFO
Save eventlog to USB stick
Eventlogs are stored to a USB stick in the directory
\pm5_log
INFO
Inserting and removing a USB memory stick
See chapter USB interface.
