26.3.2.2 Configuration 4-20mA current output
Only for control with 4-20 mAcurrent output:
This menu configures the 4-20 mA current output for the filter pump
control.
INFO
Plug-in module PM5-SA4 needed
To trigger the filter pump via a 4-20 mA current output,
the following optional plug-in module is needed:
PM5-SA4 CONVERTER 4-20MA (Art. no. 127011)
Configuration power output 4-20 mA
Relay output 'Filter pump
on/off'
Relay switch output for turning on the filter pump
(for conventional filter pumps or as
superordinate on/off switch for variable filter
pumps).
Power output used
Power output for triggering the filter pump.
Power for pump off
Entry of currents in [mA], which the power
output used sets for the various operating
modes.
Power for
reduced output
Power for normal
operation
Power for increased output
26.3.2.3 External switches
The filter pump control can be linked with up to three external switches
or push-buttons that facilitate switching on or off manually or activating
a certain operating mode.
The following settings can be configured:
Sub-menus External switch 1 / 2 / 3
External switch
1 / 2 / 3
Selection of an input to which the external switch is
connected
(IN 1 [6] / IN 2 [7] / IN 3 [8] / IN 4 [9] / none)
Type of external
switch
On/off switch or push-button.
For on/off switch only
External switch on
Defines the operating mode when external
switch is turned on:
 Filter pump off
 Normal mode / eco mode /
increased mode
 Filter pump AUTO,
(Operating mode controlled by PoolManager
®
)
External switch off
Defines the operating mode when external
switch is turned off:
 Filter pump off
 Normal mode / eco mode /
increased mode
 Filter pump AUTO,
(Operating mode controlled by PoolManager
®
)
For push-button only
Function of external
push-button
Switch off / normal / off / ... or
switch off / low / normal / high / off / ...
26.3.2.4 Dosing Settings
Here, you can define the operating modes in which dosing is blocked
for pH control and disinfection.
Sub-menu Dosing Settings
Dosing in
increased mode
On / off
Standard = off
Dosing in
eco mode
On / off
Standard = off
HAZARD!
Gaseous chlorine produced from dosing
with too little water circulation
When dosing in water with very little circulation,
poisonous gaseous chlorine can be produced when
sodium hypochlorite and pH minus meet.
Potential consequence: Death or the gravest
degree of injury, heavy material damage.
 Only activate dosing in eco mode if good circulation
and quick transportation of the dosed maintenance
produced are secured.
 In cases of doubt, block dosing for reduced output.
INFO
Dosing for increased output
pH and redox measurements are generally barely
affected by flow. Therefore, it is not absolutely
necessary to block dosing in increased mode.
For maximum safety, however, blocking is
recommended.
Direct measurement of free chlorine or bromine is flow
dependent to a certain level. Therefore, it is
recommended to disable dosing in increased mode for
the PoolManager
®
PRO.
26.3.3 Safety settings
HAZARD!
Hazard via remote access to
filter pump control
Turning on a filter pump in remote access can yield
hazards for bathers (e.g. due to current or suction
effects).
Potential consequence: Death or the gravest
degree of injury, heavy material damage.
 Remote access to filter pump control is expressly
PROHIBITED for all applications in which the
safety of persons, animals, and property is not
completely guaranteed at all times and under all
circumstances, and in particular in case of remote
access.
 Safety is exclusively in the system operator's
sphere of responsibility.
 The controller manufacturer disclaims all liability.
The following safety settings are available:
Sub-menu Safety settings
Allow filter pump
remote access
Potential settings:
 Inactive
 Local network
 Local network & Web
Show in
Mode menu
Yes / no
