41 Commissioning
PoolManager
®
has a menu for the first start-up. This menu covers all
parameters relevant to successful installation.
This menu for first start-up can be called up at any time as follows:
 Service functions  Commissioning step by step
The following steps are executed:
Action
Entry
Step 1: Menu language
Configuration of menu language
Step 2: Set default values
Here, the desired default set
can be selected and
activated.
Here, select the default set that best fits. In
cases of doubt, please check all default
values for their validity for the respective
installation.
For safety reasons, activation of the defaults
has to be confirmed at this point.
Step 3: System parameters
Configuration of pool and
system parameters
Pool volume of the connected swimming
pool.
Hose configuration of the pump hoses used.
This display is used to check the settings
made at the factory according to device
configuration.
Variation A: PoolManager
®
Oxygen:
Step 4: Calibration
Calibration (comparison) of
measured pH value
1-point calibration pH. Please proceed as
described in the section Calibration pH.
Step 5: Control parameters pH
Configuration of the most
important parameters for
pH control
When refilling the pool, it may be sensible to
expand the top and bottom pH value alarms
and to adjust the p-range, as the pH value
can fluctuate somewhat during the starting
phase.
CAUTION: If the parameters are changed,
make absolutely sure that the values are set
back as soon as the pool water has
stabilised.
You can also use the configuration assistant.
Step 6: Manual dos. O2 (Bayrosoft
®
)
Start manual dosing
The dosing volume (for 0.5l Bayrosoft
®
/10m
3
water volume) is calculated upon entering the
pool volume and can be started here.
In order to increase the dosage volume for
the first dosage, thereby increasing the
certainty of disinfection, it's also possible to
select 2x or 3x the dosage volume.
Step 7: Dosage parameters O2
Configuration of the most
important parameters for
automatic Bayrosoft
®
dosing.
Dosage volume is calculated by entering the
pool volume and is displayed here to check
(0.5l Bayrosoft
®
/10m
3
water volume). It can
be changed manually.
Select the dosage day such that it is directly
before the largest water usage expected
(e.g. high amount of swimming).
Temperature compensation ensures that
more Bayrosoft
®
is dosed for higher water
temperatures (higher product consumption). It
should be set at least to normal.
Variation B: PoolManager
®
Chlorine/Bromine
Step 4: Calibration
Calibration (comparison) of
measured value for pH and
redox
1-point calibration pH. Please proceed as
described in the section Calibration pH.
1-point calibration mV (optional). Please
proceed as described in the section
Calibration redox (mV).
Step 5: Control parameters pH
Configuration of the most
important parameters for
pH control
When refilling the pool, it may be sensible to
expand the top and bottom pH value alarms
and to adjust the p-range, as the pH value
can fluctuate somewhat during the starting
phase.
CAUTION: If the parameters are changed,
make absolutely sure that the values are set
back as soon as the pool water has
stabilised.
You can also use the configuration assistant.
Step 6: pH Value configuration
Possibility for automatically /
manually setting the pH value
in the pool water
Display shows the configured pH setpoint and
the current pH value in the pool water.
NOTE The pool water's pH value first has to
be set to pH 7.2 in order to facilitate
configuration of the redox value without issue.
Set pH operation mode to auto if
PoolManager
®
should make the configuration
fully automated. This process will take some
time, depending on pool size and water
quality.
Set operating mode to manual if you would
like to configure the pH value via manual
addition of pH-elevator and -reducer.
Step 7: Manual dosing mV (Cl / Br)
Configure the desired
chlorine or bromine level and
calculate the associated
redox (mV) value
The matching setpoint will depend on the
pool. It has to be calculated for the water in
the respective pool. Proceed as follows:
Set the pH value to pH 7.2
(see previous step)
Set the desired chlorine level in the pool via
manual dosing (or via manual addition of
chlorine) The volume of sodium hypochlorite
dosed is determined by PoolManager
®
via
the pool volume entered. This volume can be
overwritten manually.
Check the desired chlorine level via manual
measurement (DPD). The redox value in
[mV], which PoolManager
®
shows for the
desired chlorine volume, is also the value that
has to be entered as the setpoint in the next
step.
Step 8: Control parameters redox (mV)
Configuration of the most
important parameters for
redox control
Set the mV value as the setpoint you read in
the previous step for the desired chlorine
level. Adjust the bottom and top alarm
accordingly. Check the proportional range.
You can also use the configuration assistant.
In the individual menu pages, it is possible to scroll forward and
backward at any time.
For further information, please refer to the corresponding chapters in
this user's manual or to the help function on the device.
