Required user qualification:
IT SPECIALIST
Setting up e-mail functions, especially accounts for
sending e-mail (SMTP) may only be performed by an IT
SPECIALIST as defined in the chapter User
qualification.
If PoolManager
®
has a connection to the Internet (see Remote access
from the Internet), then it is able to send e-mails.
The following functions can then be realised:
Alarm e-mails
Automatic transmission of measurement graphs
E-mail functions are configured in the menu E-mail configuration.
There, the following options are available:
Menu E-mail configuration
Recipient e-mail address configuration
This sub-menu can be used to configure up to three recipient e-mail
addresses and to activate or deactivate them individually.
Account for sending e-mails (SMTP)
In this sub-menu, the account is set-up that PoolManager
®
uses for sending
e-mails. To do so, you'll need an SMTP account from an e-mail provider
(SMTP = simple mail transfer protocol) and need to have the corresponding
access information available.
You can use this sub-menu to configure the cases in which recipients will
receive alarm e-mails.
This function sends a test e-mail to the active e-mail recipients.
24 Add-on functions
PoolManager
®
provides comprehensive add-on functions for intelligent
control of numerous systems in the swimming pool environment.
You can call up the menu Add-on functions at any time as follows:
Menu hotkey
Add-on functions
The menu Add-on functions is realised as an icon menu. Every
individual add-on function is represented by its own icon.
The individual add-on functions are described in detail in the following
sections.
25 Universal switch outputs (4x)
25.1 Safety information
Required user qualification:
TRAINED SPECIALIST or
ELECTRICAL SPECIALIST
Connection, configuration, and start-up of universal
switch outputs may only be performed by a TRAINED
SPECIALIST or an ELECTRICAL SPECIALIST as
defined in the chapter User qualification.
Hazardous applications
Universal switch outputs can fundamentally be used for
the widest variety of functions. Depending upon the
application, switching processes or the switched
function could produce hazards.
Potential consequence: Death or the gravest
degree of injury, heavy material damage.
The use of universal switch outputs is expressly
PROHIBITED for all applications in which the
safety of persons, animals, and property is not
completely guaranteed at all times and under all
circumstances.
It is particularly prohibited to connect sauna
heaters without the corresponding safety
precautions (fire hazard!)
It is particularly prohibited to open and close
swimming pool covers without the corresponding
safety precautions (danger of drowning!)
Safety is exclusively in the system operator's
sphere of responsibility.
The system operator must perform a hazard
analysis for every application planned.
The controller manufacturer disclaims all liability.
25.2 Overview
PoolManager
®
provides four universal switch outputs that facilitate
intelligent and highly flexible control of water attractions and other
functions in the swimming pool environment.
There is a relay switch with the corresponding connection terminal
assigned to each switch output.
The particular features of the universal switch outputs are:
Operation optionally as volt-free switch or as 230 V~-output
Freely selectable names
Flexibly programmable timers for each switch output
Interval operation possible (turning on and off periodically)
Potential blocking in the event of missing flow
Potential blocking dependent upon the filter pump's operation
Potential blocking via an input
Potential blocking via another output
Link with an external switch or push-button
Remote access can be individually released or blocked for each
individual switch output
Show in the Mode menu can be individually released or blocked
for each individual switch output
