3.7 Technical Data
Conduction: 3-channel
Frequency Range: Event: 0.3 Hz - 75 Hz
Loop: 0.1 Hz - 75 Hz
Sampling Rate: 200 Hz
A/D Resolution: 12 Bit
Input Impedance: 9 MΩ
Sensitivity: 5 mV
Event Case Electrodes: 4 Ag/AgCl on the reverse of the Beam
®
Loop/Event cable single-
use electrodes:
cable connector for 4 standard single-use electrodes
Ag/AgCl
Event Period: adjustable (15 sec to 3 min)
Loop Period: Time before activation: 15 sec to 3 min (in 15 sec inter-
vals)
Time after activation: 15 sec to 3 min (in 15 sec inter-
vals)
Recordable Events: dependent from the set event period
Event Transmission
(e-health):
Via Mobile (GPRS) after each reading
Memory Capacity 16Mbit
maximum of 28 minutes
Battery Capacity: Event-Mode: 40 days at BT-transmission
46 without, for 5 events at 15 seconds
each per day
Loop-Mode: 10 days for BT-transmissions
for 5 events at 15 seconds each per day
Streaming: 7 hours of permanent transmission
Operating Temperature: +10°C to +45°C
Operating Humidity: 10% to 95%
Storage Environment: -20°C to 50°C and 10% to 95% humidity
Dimensions: 91 x 67 x 25 mm
Weight: ca. 102g including batteries
Power: 1 Alkali 1,5 V Battery ( AAA, LR03, Micro)
Interfaces: Bluetooth (Class 2 / 30 m)
Writing Speed: mm/sek adjustable in the HMS CS
Summer/Winter time no automatic adjustment
