4.8.8 Complete recorder preparation
► Click on
.
The prepare recorder window disappears and the recorder cancels the Bluetooth
connection with an audible signal.
4.8.8 Activate recording mode of ECG Recorder Beam
®
After you finished the preparations of the recorder in the HMS CS program the
recorder can be put into the bag and attached to a belt on the patient.
The recorder is activated automatically when the batteries are inserted and no
Bluetooth connection is active.
4.9 Read out recordings from recorder
If you have not worked with the e-health service and already have received the recor-
dings telemetrically you can read out the recordings via the Bluetooth interface.
The following steps are processed:
- Connect the HMS CS with the recorder, see 4.7 Connection via Bluetooth
®
- Transfer recordings from recorder, see 4.7, Read recordings from ECG
Recorder Beam
®
via Bluetooth
► Start the HMS CS program.
Assuming the respective program settings the Patient List window appears (see
4.13.8, Options). In this case select any patient (see 4.6.2, Select already cre-
ated patient).
► Bring your ECG Recorder Beam
®
into the communication mode by pressing
and holding for 3 seconds.
► The HMS CS program checks if a patient ID is available on the recorder.
If yes If not
A prompt appears: The patient-ID in the
measuring device (XXX) corresponds to
XXX. Should the series of measurements
be assigned to the patient?
► Click on
.
► Select the desired patient, see
4.6.2, Select already created
patient).
The recordings are transferred to the HMS CS program and saved to the patient.
A window with the following information appears: XXX measurements transferred.
Click on
.
A window with the following prompt appears: There are still series of measurements
saved in this recorder. Should the series of measurements be deleted?
