Settings
49
isoxx1685Dx-x25_D00272_07_M_XXEN/09.2022
8.2 (1.7.4.2) Function 1
The following parameters can be set:
8.2 (1.7.4.3) Function 2
See chapter 8.2 (1.7.4.2) "Function 1”.
8.2 (1.7.4.4) Function 3
See chapter 8.2 (1.7.4.2) "Function 1”.
•off The function is not used.
•Ins. alarm 1 The status of the output changes when the value falls below the set
response value R
an1.
•Ins. alarm 2 The status of the output changes when the value falls below the set
response value R
an2.
•Connection fault The status of the output changes when one of the following connec-
tion faults occurs:
No low-resistance connection between the line conductors.
No low-resistance connection of terminals E and KE to earth (PE).
•Device error The status of the output changes in the event of an internal device
error.
•Common alarm The status of the output changes on the occurrence of any alarm
and fault messages
(Ins. alarm 1 & 2, DC-/DC+ alarm, symmetrical alarm, connection
faults and device errors).
•Device inactive The status of the output changes when the device has been deacti-
vated via a digital input or the control menu.
