Operating from a Keypad
LED Keypads
Table 3 shows the meaning of the real-time signals on the Keypad LEDs.
‘View Trouble’ mode
Table 4 shows how the Keypad lights will signal the various Troubles.
Press
ENTER to access the ‘View Trouble’ mode from ‘Normal’ status (Con-
trol panel Armed or Disarmed)
Press ESC to exit the ‘View Trouble’ mode
The ‘View Trouble’ mode will end automatically after 15 seconds of inactivity.
Exit will be confirmed by an audible signal (Buzz).

 

