Bentel Security KYO 4M User Manual

32
Multifunction Control Panel

Zones Status
This option will allow you to:
a) View the zone ztatus (normal or alarm);
b) Bypass/Unbypass zones.
To program/view the zones from an LCD keypad, proceed as follows:
1. From the Main User Menu, using key
C or D
scroll the menu for the Zone Status option, then
press
ENTER.
2. To unbypass/bypass or view the zones, use keys:
C or D to Select the zone.
ON to unbypass the selected zone
OFF to bypass the selected zone
3. Press
ENTER to confirm the operation and go back to step 1.
If your installer has set up your system to signal zone alarms, the zones will
be shown at 2 seconds intervals.
To
manage, bypass/unbypass zones from an LED keypad, proceed as follows:
1. Enter a Main User Code then press the ESC key.
Code PIN + ESC
After entering the Zone Exclusion Menu and depending on the number of
zones excluded, one or more of the red indicator lights (numbered 1 to 8)
may be illuminated.
In LED keypads, the zone status is only displayed for the first 8 zones.
If the red indicator light is illuminated, this indicates that the zone has been
excluded..
2. Enter the number of the zone you wish to exclude/include (the value should
always be entered in a 2-digit format, for example 01, 02, 12, etc.), making
sure you observe the limits dictated by the control unit used..
3. Press ENTER to confirm and exit the Bypass Zones menu.
USER MENU ßà
Zones Status
Zone 1
BypassedNormal
LCD Keypads
Unbypassed/
Bypassed Zones
LED Keypads
