38
Multifunction Control Panel
The ECLIPSE Key and PROXI Card Readers simplify system control by repla-
cing User PINs with high Security Digital keys or cards. The Readers have 3
LEDs, this section describes how the LEDs work.
No Key/Card at Reader
When there is no key/card at the Reader, the LEDs will signal as per Table 16.
The partitions which are not controlled by the Reader will not affect the LEDs.
If the configuration of the Armed partitions does not match A or B Mode (for
example, when one of the Reader partitions has been Armed at a keypad), neither
the Amber nor Green LED will turn ON.
Your installer can program the Reader LEDs to signal the system status at
all times, or alternatively, only in response to a valid key/card (LEDs OFF
when no Key/Card is present).
Key/Card at Reader
When a key/card is present at the Reader, the LEDs will signal as follows.
a) Fast Blinking on 1 LED - Before arming the partitions, the Control panel
will check the status of the unbypassed (ON) and Instant zones. If a zone is
‘Violated’ (e.g. door or window open), the LED, associated with the selected
Arming Mode, will blink quickly. If this occurs, DO NOT ARM the System,
as arming will provoke a false alarm.
NOTE: The Control panel takes about 2 seconds to check all the zones.
False alarms can be stopped by simply disarming the system (refer to ‘Digital
Key/Card Readers Operations’ in this section). If a false alarm occurs, inform
your Central Station and prevent the operator from taking unnecessary action.
The Reader LEDs
*& 4',
!
5('
!"#$"
+,-
% #$"&$'""
!"#
++ !"#$"
,-
% ("$"&$'""
!"#
<(//2:
!"#$" "
++
$")"$" !"#"$
$"
*5((1
!"#$" $"
++
$")"$" !"#"$
"
