16-1
Chapter 16
Connecting Bewator Cotag
Readers to 4101-2 Controllers
This chapter describes how to connect 5291, 5298 and BC16 Readers
to the 4101-2 Controller via the 4422 Swipe Card Reader module. It
describes how to configure the Readers and Controller/module so
they communicate correctly.
5291 Proximity Reader
Connections
4422 5291
Module Reader Function
DØ DØ (green wire) logic Ø line
D1 D1 (white wire) logic 1 line
G R/G (brown wire) single wire LED control
ØV ØV (black wire) ground
+V Vin (red wire) +12V supply to 5291
Controller/module configuration
Using the Access Control Software, set the Interface Number to
303 in the Access Point record.
Set the jumpers on the 4422 module: JU1/JU4 position A (for
Wiegand), JU2/JU5 position B (for Wiegand), JU3/JU6
position B (for +12V supply to 5291 Reader).
5291 Reader configuration
D0/D1 must be active-low (pa10 = 0).
Single wire LED control* (xxrg = 2).
Interface number 59 (iiiiiiii = 59).
Other options can be configured to suit the application.
*Under single wire LED control (LED driven red and amber by 5291
Reader, LED driven green by host), the indicator LED lights amber
when the Reader detects the presence of a valid card and stays amber
for the hold off time, or for as long as a card is within range of the
antenna. The host lights the LED green when it has verified the card
