4101-2 Controller Installation Handbook
16-2
number and unlocked the door. The indicator LED lights red when
there is no valid card in range, unless there is too much electrical
noise in the reading area or more than one card or tag, in which case
the LED flashes amber.
5298 PIN & Proximity Reader
Connections
4422 5298
Module Reader Function
DØ DØ (CONN1-7) logic Ø line
D1 D1 (CONN1-8) logic 1 line
G R/G (CONN1-6) single wire LED control
ØV ØV (CONN1-2) ground
+V Vin (CONN1-1) +12V supply to 5298
Controller/module configuration
• Using the Access Control Software, set the Interface Number to
303 in the Access Point record.
• Using the Access Control Software, choose the number of
digits you want in each PIN (4, 5 or 6).
• Set the jumpers on the 4422 module: JU1/JU4 position A (for
Wiegand), JU2/JU5 position B (for Wiegand), JU3/JU6
position B (for +12V supply to 5298 Reader).
5298 Reader configuration
• JU1 must be set to 5/15 (this is the default setting).
• D0/D1 must be active-low (pa10 = 0).
• Single wire LED control* (xxrg = 2).
• Interface number 59 (iiiiiiii = 59).
• Other options can be configured to suit the application.
*Under single wire LED control (LED driven red and amber by 5298
Reader, LED driven green by host), the indicator LED works as
follows:
• The LED is red when no card or tag is in range.
• When the Reader reads a valid card or tag, the LED goes off
and the Reader waits for the cardholder to enter PIN data on
the keypad.
