10-1
Chapter 10
4210 RF module
Description
The 4210 RF module is required in any Controller fitted with 4322
Cotag Reader modules. It provides the RF signals required to drive
the antennas. It is always fitted in its own module slot, the one
nearest the bottom of the Controller. It requires no external
connections and no setting up. Do not change the setting of RV1.
Installing the RF module and teaching the
Controller its Distributor Code
Note: if a Controller is to be used with one or more 4322 Cotag
Reader modules, you must install the RF module and teach the
Controller its Distributor Code before installing any other modules.
You do not need to teach the Distributor Code to a Controller used
only for Swipe Card Reader modules and/or I/O modules.
1. Disconnect the power to the Controller before installing the RF
module.
2. The chassis in the Controller has six module slots. The RF
module must be plugged into the bottom slot (the one with the
smaller connector).
3. With the components on the underside, slide the module down
and locate its connector with the one on the chassis.
4. Press the module home by applying downward pressure on the
board directly over the connector on the motherboard.
