Connecting Bewator Cotag Readers to 4101-2 Controllers
16-3
• The LED gives a single amber flash and horn bleep each time
the cardholder presses a key.
• When the host has processed the card data and PIN data from
the Reader, it will unlock the door and light the LED green by
pulling the R/G input down to 0V.
• When the host releases the R/G input, the LED returns to red.
• The LED flashes amber if there is electrical noise in the
reading area which may affect reading of cards and tags, or if
there is more than one card or tag in the reading area at the
same time.
BC16 Mag Stripe Reader
(with IP1 cards coded with 8 digit card numbers in standard Mag
Stripe / ABA format)
Connections
4422 BC16
Module Reader Function
DØ blue wire strobe
D1 yellow wire data
R brown wire red LED
A amber wire amber LED
G green wire green LED
ØV black wire ground
+V red wire +5V supply to BC16
Controller/module configuration
• Using the Access Control Software, set the Interface Number to
361 in the Access Point record.
• Set the jumpers on the 4422 module: JU1/JU4 position A (for
Mag Stripe), JU2/JU5 position A (for active-low strobe),
JU3/JU6 position A (for +5V supply to BC16 Reader).
BC16 Reader configuration
No configuration required.
