4322 Cotag Reader module
4-3
a 4320 module does not support the 4922 Dual PINpad Data
Adapter.
4322 operation If JU7 is moved to the Mk2 position the 4322 Cotag
Reader module is only supported by the following:
• Access Control Software version 4 or later
• Mk2 4101 Controllers with firmware version 2/64.3A or later
• 4010 Controllers with firmware version 2/60.4A or later
With JU7 in the Mk2 position the module is recognised as a 4322
Cotag Reader module by the Access Control Software, and the module
supports the 4922 Dual PINpad Data Adapter.
LEDs
There is an amber LED for each reader which lights when the
transmit is active, that is, when the Controller is polling the reader.
If the LED is not flashing then the reader is not being polled and no
cards can be read. This is either because the reader is not configured
in the Software, or the Software database has not been downloaded to
the Controller.
Connecting
External connections are made to the Controller via cables which can
enter through holes in any part of the case using the knockouts
provided. Cables connecting to modules plugged into the
motherboard should be routed to each side of the chassis where there
are cable guides provided. This ensures modules can be removed
easily without cables snagging.
All connections to the module are made to the strip of green
connectors along the front edge of the module circuit board. There is
a duplicate set of connections on each side, one set per reader. The
connectors can be unplugged from the module so you can gain access
to the screw terminals with a screwdriver. Unplugging the connectors
also enables the module to be removed at a later date, leaving the
wiring intact.
