4101-2 Controller Installation Handbook
5-4
Wiegand card reader or 5000 series reader
The Wiegand connections are used for Wiegand card readers and for
connecting 5000 series readers (for AVI or Wanderer Control).
Module Reader Function
DØ DØ logic Ø line
D1 D1 logic 1 line
ØV -volts ground
+V +volts +5V or +12V* supply for reader (select with JU3/JU6)
*Note that the 12V supply is actually an 11.2V regulated output. However, when the
Controller is powered from the backup battery, this output may fall to 10.5V. No more than
100mA must be drawn from the +5V output and no more than 150mA from the +12V
output.
5000 series readers connected to the swipe module should be
configured so their data interfaces are set to 59.
If 5000 series readers are connected, the swipe module Access Point
records in the Access Control Software should be set to interface 303.
Use cable which is overall screened. The cable gauge depends on the
distance you wish to run it and the current drawn by the card reader.
For example, Sensor specify 18AWG (0.75mm
2
) conductors for up to
160 metres. See the card reader manufacturer’s specification. The
cable screen should be connected to the Controller case, see the
chapter on “Earthing and screening”.
Magnetic Stripe
Module Reader Function
DØ strobe clock
D1 data data line
ØV -volts ground
+V +volts +5V or +12V* supply for reader (select with JU3/JU6)
*Note that the 12V supply is actually an 11.2V regulated output. However, when the
Controller is powered from the backup battery, this output may fall to 10.5V. No more than
100mA must be drawn from the +5V output and no more than 150mA from the +12V
output.
