Fit ferrite sleeve
(part number Q122)
over cable inner
wires as soon as
cable enters chassis
Connect screen
to nearest
binding post
)+,"-#.2
"!&5
$ %
)+,-.
Mains input
printed circuit
assembly
Fit ferrite sleeve
(part number Q123)
over mains cable
Lower part of Power Supply Unit
(not to scale)
To Next Page
