BEWATOR COTAG 4101-2 - Reader Module Wiring Diagrams

Wiring diagrams
A-1-3
Cotag Reader module and 280 Reading Head
VA
G
R
RX
RX
TX
TX
RX
RX
TX
TX
V+
D3 (G)
D2 (A)
D1 (R)
brown
green
orange
red
black/white
pair
black/red
pair
A
4101-2 Controller
motherboard
0 1
280 Reading Head
(viewed from front
with cover removed)
Cotag Reader module in slot 0/1
1 2 3 4
Cotag Reader module and 090 Reading Head
VA
G
R
RX
RX
TX
TX
brown
green
red
black/white
pair
black/red
pair
4101-2 Controller
motherboard
0 1
Cotag Reader module in slot 0/1
5 (LED)
4 (LED)
3 (V+)
Connector in
090 Reading Head
(viewed from rear)
6 (RX)
7 (RX)
1 (TX)
2 (TX)
1 2 3 4
