AudiaEXPI-D Digital Input Expander
ARCHITECT'S & ENGINEER'S SPECIFICATION
The Digital Input Expander shall provide four pairs of AES3 transformer
coupled digital audio inputs on XLR connectors. Two of these pairs shall be
selectable instead as SPDIF inputs on RCA connectors and the other two pairs
shall be selectable instead as TOSLINK inputs. Eight channels of digital audio
output shall be provided via CobraNet, on two rear panel RJ45 connectors. A
word clock output shall be provided on BNC connector. A rotary encoder and LCD
screen shall be provided on the front panel for programming and setup. Logic
Inputs shall be provided for recalling preset configurations.
The Digital Input Expander shall be represented as a functional block within
AUDIA® software, for easy inclusion into system designs. The Digital Input
Expander shall also be capable of providing digital audio inputs to other
CobraNet compliant systems or devices. The Digital Input Expander shall be CE
marked, include a UL listed power source, and carry a five-year warranty.
The Digital Input Expander shall be AudiaEXPI-D.
AudiaEXPO-D Digital Output Expander
ARCHITECT'S & ENGINEER'S SPECIFICATION
The Digital Output Expander shall provide eight channels of digital audio
input via CobraNet, on two rear panel RJ45 connectors. Four pairs of AES3
transformer coupled digital audio outputs shall be provided on XLR connectors.
Two of these pairs shall be available also as SPDIF outputs on RCA connectors,
and the other two pairs shall be available also as TOSLINK outputs. A word
clock output shall be provided on BNC connector. A rotary encoder and LCD
screen shall be provided on the front panel for programming and setup. Logic
Inputs shall be provided for recalling preset configurations.
The Digital Output Expander shall be represented as a functional block within
AUDIA® software, for easy inclusion into system designs. The Digital Output
Expander shall also be capable of providing digital audio outputs from other
CobraNet compliant systems or devices. The Output Expander shall be CE marked,
include a UL listed power source, and carry a five-year warranty.
The Digital Output Expander shall be AudiaEXPO-D.
Documentation
The information contained in this Help file can be printed in manual form (with Table of Contents and Index).
Two PDF
documents are provided on the software CD-ROM for this purpose. The file AUDIA.pdf is
intended for printing on Letter (8.5" x 11") size paper. The file AUDIA-A4.pdf is intended for printing on A4
(210mm x 297mm) size paper. These are printable Help files. Similar PDF files are also available on the
software CD-ROM, for the 'RS-232 & Telnet Protocol' and the 'Quick Start Guide & Safety Information'
documents.
