Component Objects
Input Output
These Component Objects provide the audio inputs/outputs (I/O) to the system. Analog and CobraNet™
(digital) I/O are both available, allowing system designs to include A/D & D/A converters which have
CobraNet™ capability. AEC Input components are available, for acoustic echo cancellation, and a
Telephone Interface is available for conferencing. Input/Output components are available in pre-defined
configurations, however, the configuration may be customized when being placed from the Object Toolbar.
Once a Component Object is placed into the Layout, all available settings can be accessed by double-
clicking over the object. This produces a Control Dialog Box, which displays the component controls in a
more conventional user interface.
see Input Control Dialog
see Output Control Dialog
see CobraNet Input Control Dialog
see CobraNet Output Control Dialog
see Fixed 12-Channel Input Control Dialog
see Fixed 12-Channel Output Control Dialog
see AEC Input Control Dialog
see EXPI Control Dialog
see EXPO Control Dialog
see EXPI-D Control Dialog
see EXPO-D Control Dialog
see Telephone Interface Control Dialog
Right-clicking over the object provides a pop-up menu of options.
