Controls
These Component Objects provide both internal and external control functions. Level Controls, Mute
Buttons, and Invert may be connected between components within the Layout, for control of volume,
muting, and polarity. Preset and Remote Preset Buttons may be placed within the Layout, and defined to
recall specified Presets. Logic Gates and Logic Delay may be connected between component control
nodes in the layout, to customize control behavior. Command Strings can provide serial control of external
devices, when triggered by control nodes on other components in the layout. Event Schedulers can provide
timed triggering of internal or external events. Volume 8, Select 8, Volume/Select 8, and Logic Box
components may be placed within the layout, to represent their corresponding external control devices.
Controls are available in pre-defined configurations, however, the configuration may be customized when
being placed from the Object Toolbar.
Once a Component Object is placed into the Layout, all available settings can be accessed by double-
clicking over the object. This produces a Control Dialog Box, which displays the component controls in a
more conventional user interface.
see Level Control Dialog
see Level Inc/Dec Control Dialog
see Invert Control Dialog
see Mute Button Control Dialog
see Preset Button Control Dialog
see Remote Preset Button Control Dialog
see Logic Gates
see Logic Delay Control Dialog
see Command String Control Dialog
see Event Scheduler Control Dialog
see Volume 8 Control Dialog
see Select 8
see Volume/Select 8 Control Dialog
see Logic Box
Right-clicking over the object provides a pop-up menu of options. Control Dialog Boxes for Level, Mute,
and Preset related components can be minimized to create user control surfaces (see Customizing
Component Objects).
