Layout Toolbar
The Layout Toolbar affects certain aspects of Layout, such as the grid, rulers, zooming, & alignment of
Component Objects. The Layout Toolbar can also open editing/information sheets for properties, objects, &
layers. The available tools are: Property Sheet; Object Inspector; Layers Sheet; Toggle Grid; Toggle
Ruler; Bird's Eye View; Zoom In; Zoom Out; Zoom 1:1; Zoom Level; Pack Objects; Align Edges;
Center In View; Space; Make Same Size; and To Front Or Back. The Layout Toolbar may be
opened/closed from the View Menu. The location and shape of all toolbars may be changed to fit the user's
preference.
Tools
Property Sheet
Provides an editable table of attributes regarding the
Layout and its associated objects. Only Display Attributes
are shown for the Layout (and Lines). Both Display and
DSP Attributes are shown for Component Objects.
see Layout Property Sheet
see Line Property Sheet
see Object Property Sheet
