CB (E7) 06/2018 Page 124/174
18. Options
18.1 Communication software APT-COM™ 3 DataControlSystem (option)
The chamber is regularly equipped with an Ethernet interface (5) that can connect the BINDER
communication software APT-COM™ 3 DataControlSystem. The actual values of temperature, CO
2
, O
2
(chamber with O
2
control) and humidity (chamber with active humidification) are given at adjustable
intervals. Programming can be performed graphically via PC. Up to 40 chambers can be cross-linked.
The MAC Address is indicated in the “Device info” controller menu (chap. 14.5.2.2). For further
information on networking please refer to the operating manual of the BINDER communication software
APT-COM™ 3.
18.2 Silicone access ports 30 mm / 1.18 in, closable from both sides with silicon
plugs (option)
(a)
(b)
(c)
Figure 21: Positions of the optional silicon access ports left (a), rear (b), and right (c)
A warning sticker is located above each access port on the outside of the incubator.
