BM5 (CS,CX) User’s Manual
ZERO ART: (Zero-point Adjustment)
Use ZERO option to set the zero-point of Transducer.
SETTINGZERO
CHANGE
NAME
:ART
SCALE:
160
ALARM
MAIN
MENU
Procedures (Zero reference)
1) Close the transducer stopcock on the patient’s side.
2) Open the venting stopcock on the air side.
3) Press the knob switch on the monitor panel.
4) Draw a line with the current input data in IBP area of WAVE WINDOW according to the
Wave Base Line. And accord the wave line with the data.
5) Set the data as ‘0’ on the parameter screen.
6) Check if Zero reference is carried out. (Check the pressure parameter on the message
window.)
7) Close the venting stopcock on the air side.
8) Open the transducer stopcock on the patient side. The pressure value should be displayed
on the pressure parameter screen in a few seconds.
Troubleshootings for a case that blood pressure value is not displayed on screen
In case of ‘out of measurement range’
situation
Check the measurement conditions.
In case blood pressure transducer is
damaged
Replace the damaged transducer with new
one
All parts, except Transducer, should not be conductive. Otherwise discharge energy may induce
a shock to operators during cardioversion.
