26 | Chapter 2: Installation
9. Locate and install the gripper arm cover using the small Phillips-head
screwdriver.
10. For safekeeping, screw all the screws and washers, the small shipping brackets
and the large shipping block onto the large shipping bracket. Store the shipping
hardware with all the other packaging materials in the shipping boxes and keep
for future use.
Wrist Angle Setting Requirements
Each instrument requires the BioStack to have a certain wrist angle setting:
l The BIOSTACK2WR ships with the wrist angle set to 90°; its other setting is 0°.
l The BIOSTACK3WR/BIOSTACK4 ships with the wrist angle set to +90°; its other
settings are 0° and -90°.
Instrument BIOSTACK2WR BIOSTACK3WR/BIOSTACK4
Liquid Handlers
405 TS, 405 LS* 90° +90°
EL406, ELx405* 90° +90°
MicroFlo Select* 90° N/A
MultiFlo, MultiFlo FX* 90° +90°
Precision/XS, MicroFill 0° N/A
Readers
Cytation 1, 3, 5 N/A +90°
Eon 0° 0°
EpochR 0° -90°
Epoch 2 90° +90°
PowerWave HT 90° +90°
Synergy H1 90° +90°
Synergy 2, 4, MX, HT,
HTX, H4
0° -90°
Synergy Neo/Synergy
Neo2
N/A 0° (BioStack4 Only)
BioStack™ Microplate Stacker
