BK Precision MR Series User Manual

Front Panel Operation 24
3. Use numerical keys directly or use keys with the rotary knob to adjust the value. Press to conrm the
OVP value.
4. Press several times to exit the menu setting.
When OVP protection is tripped during operation, the output will turn o and the following OVP status message will
display:
To clear the trip status, press once.
3.5.3 Over Current Protection (OCP)
Congure Over Current Protection (OCP) The MR overcurrent protection utilizes a hardware comparator that quickly
protects the instrument when the current presented at the output terminal exceeds the OCP setting current.
Follow the steps below to set the OCP limit:
1. Press button, select CONFIGURATION, then press .
2. Press button one time until PROTECT is select and press . The display will then show OVP.
3. Press button one time until OCP is displayed, and press .
4. Use numerical keys directly or use the keys with the rotary knob to adjust the OCP value. Press the
button to conrm the OCP value.
5. Press several times to exit the menu setting.
When OCP protection is tripped during operation, the output will turn o and the following OCP status message will
display:
To clear the trip status, press once.
