Introduction
1.1 Product Overview
Figure 1.1 MR25080: 250 V / 80 A / 5000 W
B&K Precision models MR3K160120, MR160120, MR25080, MR50040, and MR100020 are high voltage programmable
DC power supplies with single outputs that oer the maximum power output up to 5000 watts. By connecting up
to *50 power supplies in parallel, a maximum output power can reach up to 250 kW. These power supplies are fully
programmable and controllable through analog programming, USB, RS232, RS485, GPIB and Ethernet interface. The
front numerical keypad and rotary knob provide a convenient interface for adjusting voltage, current, operating functions
and enabling/disabling the output. The MR series power supplies also provide over voltage protection (OVP) and
over current protection (OCP) features used to keep the output voltage and current within a specied safety level and
preventing damage to the UUT (Unit Under Test).
Model MR3K160120 MR160120 MR25080 MR50040 MR100020
Output Voltage 0 to 160 V 0 to 250 V 0 to 500 V 0 to 1000 V
Output Current 0 to 120 A 0 to 80 A 0 to 40 A 0 to 20 A
Output Power 3000 W 5000 W
Table 1.1 Models
1.2 Contents
Please inspect the instrument mechanically and electrically upon receiving it. Unpack all items from the shipping carton,
and check for any obvious signs of physical damage that may have occurred during transportation. Report any damage
to the shipping agent immediately. Save the original packing carton for possible future reshipment. Every power supply
is shipped with the following contents:
• 1 x MR3K160120, MR160120, MR25080, MR50040, or MR100020 Power Supply
• 1 x AC Power Cord
• 1 x Certicate of Calibration
• 1 x Test Report
Note:
Ensure the presence of all the items above. Contact the distributor or B&K Precision if anything is
missing.
1.3 Features
